U.S. Air Force Valkyrie 'loyal wingman' drone launches drone of its own in new test

The XQ-58A Valkyrie (large drone) demonstrates the separation of the ALTIUS-600 small UAS in a test at the U.S. Army Yuma Proving Ground test range in March 2021. This test was the first time the Valkyrie's weapons bay doors have been opened in flight. [Photo: USAF]









The U.S. Air Force Research Laboratory successfully completed the XQ-58A Valkyrie's sixth flight test and the first release from its internal weapons bay on March 26, 2021, at Yuma Proving Ground, AZ.

This test, conducted in partnership with Kratos UAS and Area-I, demonstrated the ability to launch an ALTIUS-600 small, unmanned aircraft system (SUAS) from the internal weapons bay of the XQ-58A. Kratos, Area-I, and AFRL designed and fabricated the SUAS carriage and developed software to enable release. After successful release of the SUAS, the XQ-58A completed additional test points to expand its demonstrated operating envelope.

"This is the sixth flight of the Valkyrie and the first time the payload bay doors have been opened in flight," said Alyson Turri, demonstration program manager. "In addition to this first SUAS separation demonstration, the XQ-58A flew higher and faster than previous flights."


VIDEO: XQ-58A Valkyrie demonstrator inaugural flight back in March 2019. [Credit: U.S. Air Force Research Lab]

At 30 ft long and with a wingspan of 27 ft, the unmanned XQ-58A Valkyrie is considered a stealth "loyal wingman" drone that flies as an escort with jet fighters such as the F-22 or F-35 during combat missions. It is controlled by its parent aircraft and has a maximum speed of 650 mph using its turbofan engine. Max range is 3,000 nm. It has two weapons bays (that can contain multiple bombs or, now, at least one drone) and a total capacity up to 600 lb. It has a dry weight of 2,500 lb.

The 3-ft-long ALTIUS-600 has spring-loaded wings and supports a Multi-Domain Operations (MDO) system so it can be launched from the air, sea, or ground from systems like the Common Launch Tube (CLT), Pneumatically Integrated Launch System (PILS), and other launch systems. It was designed with a modular payload nose that can hold up to 6 lb (sensor or weapon) and has a range of 276 miles.

Sources: U.S. Air Force, Kratos, Area-I

Published April 2021
