Meet DARPA's newest X-plane: XRQ-73 flying wing

The Series Hybrid Electric Propulsion AiRcraft Demonstration program, known as SHEPARD, has its hybrid-electric uncrewed aircraft system (UAS) receive its official X-plane designation, XRQ-73. [Credit: Photo courtesy of DARPA]









The Series Hybrid Electric Propulsion AiRcraft Demonstration program, known as SHEPARD, has received its official X-plane designation from the Defense Advanced Research Projects Agency (DARPA): XRQ-73.

SHEPARD is an "X-prime" program, leveraging the series hybrid electric architecture and some of the component technologies from the earlier Air Force Research Laboratory/Intelligence Advanced Research Projects Activity (AFRL/IARPA) Great Horned Owl (GHO) project.

According to Airforce Technology, "The GHO project sought to advance the role of UAS in Intelligence, Surveillance and Reconnaissance (ISR) missions by eliminating or reducing the UAS' acoustic signature while retaining a long-range endurance. To that end the GHO propulsion system quietly generated electrical power from liquid hydrocarbon fuel, either gasoline or diesel, and then used the stored electrical energy to deliver a purely electrically driven quiet flight."

The XRQ-73 aircraft, featuring a flying wing design, will be a Group 3 unmanned aerial system (UAS) weighing approximately 1,250 lb. DARPA is keeping the physical dimensions of the craft under wraps for now. First flight of the XRQ-73 is expected by year-end 2024.

"The idea behind a DARPA X-prime program is to take emerging technologies and burn down system-level integration risks to quickly mature a new, missionized, long-endurance aircraft design that can be fielded quickly," said Steve Komadina, SHEPARD program manager. "The SHEPARD program is maturing a specific propulsion architecture and power class as an exemplar of potential benefits for the Department of Defense."

The DARPA team includes members from the Air Force Research Lab, the Office of Naval Research, and our U.S. warfighters.

The prime contractor for SHEPARD is Northrop Grumman Corporation's Aeronautics Systems sector in Redondo Beach, CA. Scaled Composites, LLC is a major supplier, along with Cornerstone Research Group, Inc.; Brayton Energy, LLC; PC Krause and Associates; and EaglePicher Technologies, LLC.

Sources: DARPA, Airforce Technology

Published July 2024
