Blended wing body aircraft: Alaska Airlines invests in innovative plane design

JetZero is developing the world's first commercial blended wing body (BWB) airplane, which is projected to enter commercial service by 2030. Alaska Airlines is an early investor. [Credit: Image courtesy of JetZero]









Alaska Airlines recently announced an investment in JetZero, a pioneering company developing a new blended wing body (BWB) aircraft that is projected by its developers to provide up to 50% less fuel burn and lower emissions.

The investment reflects Alaska's commitment to advance new technology that will benefit the future of aviation, including those that enable the airline's path to net-zero carbon emissions. Alaska invested as part of JetZero's Series A last year and is the first airline to do so.

The investment, which includes options for future aircraft orders, was made through Alaska Star Ventures (ASV), the airline's investment arm whose purpose is to influence the future of the aviation industry. ASV is focused on identifying and enabling the technologies that can help Alaska reach its ambitious goal of net-zero carbon emissions by 2040. This initiative is one piece of Alaska's comprehensive sustainability strategy along with operational efficiency, fleet renewal, sustainable aviation fuel, waste reduction, and electrified aircraft.

The JetZero BWB airplane's single-deck design features engines mounted on top, resulting in much less noise. [Credit: Image courtesy of JetZero]





JetZero's BWB aircraft stands out with its innovative design that integrates the wings and fuselage into a single smooth shape, greatly reducing aerodynamic drag. Due to an expected 50% fuel reduction compared to the current tube-and-wing design, the BWB is projected to result in potential lower carbon emissions and operating costs. The aircraft's spacious interior will enable innovative seating arrangements with benefits to passenger comfort, such as a quieter and more enjoyable flying experience. Its unique shape will significantly reduce weight and drag and offers great promise in contributing to a more sustainable future in aviation.

"Of all the great new technologies in work, the BWB design delivers the biggest impact by far," said Tom O'Leary, CEO and co-founder, JetZero. "We're thrilled to welcome Alaska to our team of innovators, and our belief that this aircraft will reshape aviation."

While the BWB design is not new, JetZero has shown unique leadership in collaborating closely with the United States Air Force, NASA, and the FAA to develop its revolutionary blended wing aircraft and ultimately bringing it to market.

JetZero was co-founded by aerospace legend Mark Page. JetZero aims to enter commercial service by 2030.

Source: JetZero

Published October 2024
