The MELFA RV-12CRL vertically articulated robot has the longest reach of any robot in Mitsubishi Electric's low-cost robot series: 1,504 mm (59.2 in.). With a 12-kg (26.4-lb) payload capacity, this unit is an ideal candidate for machine tending, case packing, and pick-and-place applications. Built-in features provide enhanced safety, streamlined implementation, and an overall reduction in downtime. Features internal cables and air hoses for end-of-arm tooling.
Learn more.
Siemens' new stainless steel SIMOTICS S-1FS2 line of servomotors has been designed for the clean condition requirements of the food, beverage, sterile packaging, pharma, and other process industries. These motors are highly resistant to corrosion and acidic chemicals and are offered in a variety of power ratings, from 0.45 to 2 kW (0.60 to 2.68 hp) with torque from 3.1 to 14 Nm (2.28 to 10.32 ft-lb). Features include high dynamics due to low inherent inertia, high overload capacity for pick-and-place, and precise movement of heavy loads. Easy installation and cleaning. Compatible with the SINAMICS S210 drive system.
Learn more.
Matt Sherman, eMobility Sales and Application Engineer at KEB America, runs through different options to drive an AC motor, including one called "Sensorless Closed Loop" that does not require additional hardware such as encoder, resolver, or cables on the motor.
Read this informative KEB America blog.
The precision and reliability offered by modern rotary encoders are essential in many product categories. These include robotics, machine tools, printing presses, motion control systems, medical equipment, aerospace, gaming and entertainment, and automotive. Learn all about magnetic rotary encoders -- and important developments in the technology's future.
Read the full Avnet article.
Tolomatic has introduced five new products in its RSX line of high-force actuators to meet a wider range of industrial applications. These five sizes expand the RSX's capabilities to include forces up to 66,000 lbf (294 kN). RSX actuators, which feature high-precision planetary roller or ball screws for longer life in harsh environments, enable the easy replacement of traditional hydraulics to eliminate leaks and improve system performance.
Learn more.
Piezoelectric motion components are highly valued for their fast response times, capable of dynamic movements at frequencies reaching several kHz, and delivering motion resolution down to the sub-nanometer level. Learn why amplified piezo actuators have the edge over traditional piezo stack actuators.
Read the full article.
Engineers from Performance Motion Devices take a comprehensive look at how to control two-phase stepper motors, beginning with the basics (operations, strengths and weaknesses) and moving on to traditional and updated advanced techniques for control including closed loop. A very thorough presentation.
Read this informative Performance Motion Devices article.
Automation-Direct has added the new SQ series table lifting systems from Ergoswiss. These lifting systems use electrically driven columns that allow the operator to reposition the height of a worktable, conveyor, etc. to meet specific requirements. In doing so, the operator can perform their tasks in a more comfortable working posture, helping to reduce work-related injuries. These systems are all electric (no hydraulic mess or manual hand cranks), and each lifting column features a housed motor and screw drive to perform the needed height adjustments.
Learn more.
The GVCM-032-025-02M Linear Voice Coil Servo Motor is the first of a new series of non-commutated, brushless linear servo motors from Moticont. This clean and quiet unit has a 12.7-mm stroke with built-in shaft and bearing, a continuous high-force-to-size ratio of 9.3 N (2.1 lb), and 29.3 N (6.6 lb) of peak force at a 10% duty cycle. Features include: high reliability, high speed, zero cogging, high acceleration/deceleration, and, when used in a servo loop, very high accuracy and repeatability. An ideal choice for: haptic feedback, medical devices, laser machining and drilling, work holding and clamping, scanners, optical focusing, testing, sorting, and assembly.
Learn more.
With the help of a motion controller and a stepper driver, all stepper motor linear actuators can be programmed to position a load to a precise location. However, standard configurations do not provide a feedback mechanism that tells the operator whether the move is completed or not. Adding an encoder can be an effective and simple solution to get real-time motion feedback about your application.
Read this informative Thomson article.
Overhead conveyor drives from NORD DRIVE-SYSTEMS are engineered with long-lasting performance and durability in mind. They feature high-quality components, heavy-duty construction, and an output mounting flange and shaft for easy drop-in replacement of industry-standard footprints. They are an ideal solution for meat and poultry processing, automotive assembly, and other manufacturing systems where utilization of vertical space is required. Lots of options and many more features.
Learn more.
maxon, a leader in DC motor and drive solutions, has unveiled its latest innovation: the ESCON 2 controller. This advanced speed and current controller, designed for micro motors, significantly enhances control precision. The ESCON 2, suitable for brushed and brushless DC motors up to 1,800 W continuous duty, is engineered for seamless OEM integration into customer systems. Enhanced control features include field-oriented control (FOC), acceleration, and velocity feed-forward capabilities. Supports 4-quadrant operation. Lots more features. Available from Electromate.
Learn more and get all the specs.
The next evolution of the award-winning Aircore EC motor from Infinitum is a high-efficiency system designed to power commercial and industrial applications such as HVAC fans, pumps, and data centers with less energy consumption, reduced emissions, and reduced waste. It features an integrated variable frequency drive and delivers upward of 93% system efficiency, as well as class-leading power and torque density in a low-footprint package that is 20% lighter than the previous version. Four sizes available.
Learn more.
Universal Robots, the pioneer of collaborative robotics, is set to unveil a new AI-powered machine tending solution at IMTS, enabling faster batch changeovers by eliminating the need for fixtures. Additionally, the company will showcase advanced cobot applications for welding, finishing, part feeding, and laser marking. Lots of useful tech here.
Read the full article.
The number of active satellites in space keeps growing, with more than 10,000 active satellites orbiting our planet. Commercial and academic institutions developing these satellites continuously work on improved test systems and methodologies to fully validate their hardware before launch. Learn why PI's 3-DOF spherical air bearing systems are an important part of this process.
Read the full article.
The Defense Advanced Research Products Agency's Falcon Hypersonic Test Vehicle emerges from its rocket nose cone and prepares to reenter Earth's atmosphere. [Credit: Image courtesy of DOD]
By David Vergun, U.S. Department of Defense
The Defense Department (DOD) is sponsoring a Hypersonics Horizon High Speed Video challenge, open to high school and undergraduate students, with cash prizes.
"The Hypersonics Horizons High Speed Video Challenge is integral to building an enduring advantage by investing in the workforce of tomorrow," said Aprille Ericsson, the assistant secretary of defense for science and technology. "The Joint Hypersonics Transition Office [JHTO] continues to cultivate and invest in future talent by utilizing our Smart Scholarship program and partnering with Academia, which develops pathways for both a diverse and technically proficient workforce to protect both our national security and American prosperity for years to come."
"The challenge is designed to inspire the next-generation workforce in hypersonics," said Mark A. Glenn, director of the Joint Hypersonics Transition Office.
Glenn said instructions for high school teams, of up to three students, involve making a three-to-five-minute video explaining the type of challenges a spacecraft might encounter on Mercury, Venus, Titan (Saturn's moon), Ceres (asteroid), or Pluto. They would also have to address how the spacecraft design would be impacted by challenges of their chosen celestial body's environment and would need to explain how they would overcome those issues.
A X-60A hot fire test is conducted at Cecil Spaceport in Jacksonville, FL, Jan. 14, 2020. The X-60A, developed through an Air Force Research Laboratory Small Business Innovation Research contract, is an air-launched rocket designed for hypersonic flight research. [Credit: Image courtesy of U.S. Air Force]
For post-secondary student teams, Glenn said students are required to make a three-to-five-minute video discussing a design for a plane-like spacecraft engineered to launch, reach hypersonic speeds, and safely touch down on Mars. Then they must address challenges the spacecraft and astronauts may face upon landing. He added that the problem sets involve multidisciplinary challenges and solutions, so students can pull from diverse subject matter, not just physics and engineering.
Lori Michelle Stiglitz, JHTO workforce development lead, said this is the second year for a challenge involving hypersonics.
Last year's challenge involved ways to transport people at hypersonic speeds. Many college and high school students applied, and the students as well as their science and engineering teachers were enthusiastic about it. The students conducted research, delving into many open-source documents on the topic and related topics, she said.
One of last year's university students who participated in the challenge looks to pivot to hypersonics in grad school, Stiglitz added.
Last year's high school winner knew nothing about hypersonics, "so he took a deep dive into hypersonics and he's sharing his knowledge with all of the students, teachers, and administrators at his high school. Some of the physics teachers didn't even know about the topic. So that knowledge is spreading," she said.
"Kids are very creative and enthusiastic about hypersonics. We get to gather their unique mindsets in hypersonics problems," she said.
Awards are planned to be announced in February after evaluators who work across the DOD hypersonics community provide their feedback and assessment. They might also gain novel insights by this challenge, she added.
About a month ago, Stiglitz said she spoke to about 300 mechanical engineers at Montana State University and shared the upcoming challenge with them, and they all started chatting eagerly about it.
For more details about the competition, Hypersonic Horizons 2024: The High Speed Video Challenge, visit the challenge entry web page here.
Published October 2024
