Can an injected polymer help your tissues heal after a heart attack?

Researchers have developed a new therapy that can be injected intravenously right after a heart attack to promote healing and prevent heart failure.

The therapy both prompts the immune system to encourage tissue repair and promotes survival of heart muscle cells after a heart attack. Researchers tested the therapy in rats and showed that it is effective up to five weeks after injection.

The research team, led by bioengineers at the University of California - San Diego and chemists at Northwestern University, published their findings in the April 25 issue of the journal Advanced Materials.

"Preventing heart failure after a heart attack is still a major unmet clinical need," said Karen Christman, one of the study's corresponding authors and a professor in the Shu Chien-Gene Lay Department of Bioengineering at the UC San Diego Jacobs School of Engineering. "The goal of this therapy is to intervene very soon after someone suffers a heart attack to keep them from ultimately going into heart failure."

Side-by-side comparison of heart muscle cells with and without treatment. Damage to the cells is shown in blue. On the left, tissue has been injected with saline and the damaged area is considerably larger. On the right, the issue was treated with the PLP platform and the damaged area is significantly smaller. [Credit: Image courtesy of University of California San Diego/Northwestern University]









The therapy could have broader applications, said Nathan Gianneschi, the paper's other corresponding author and a professor in the Department of Chemistry at Northwestern.

"This therapeutic platform has tremendous potential for several diseases, including everything from macular degeneration to multiple sclerosis and kidney disease," Gianneschi said.

The platform aims to block the interaction of two key proteins that intervene in the body's response to stress and inflammation. When the protein Nrf2 is activated, cells resist the degradation brought on by inflammation. But KEAP1 binds with Nrf2 to degrade it in turn. After a heart attack, this process of degradation has to be stopped so that tissues can heal better.

The protein-like polymer, or PLP, platform is made from a polymer that mimics Nrf2. Once injected intravenously, it finds KEAP1 and binds to it, preventing it from binding to the actual Nrf2 protein and degrading it.

Researchers injected rat models after a heart attack with either the PLP platform or a saline solution. The team was blinded to which animals received the polymer or saline. After five weeks, the rodents underwent MRIs while sedated. The animals injected with the polymer showed better cardiac function and significantly more healing in their heart muscle tissue. Other tests also showed that genes that promote healing of tissues were expressed more.

Researchers describe the study as a proof of concept. Before moving on to tests in larger mammals, they want to optimize the design and dosage, and conduct further analysis.

"Proteins are the molecular machines that drive all essential cellular function, and dysregulated intracellular protein-protein interactions are the cause of many human diseases," Gianneschi said. "Existing drug modalities are either unable to penetrate cells or cannot effectively engage these large disease target domains. We are looking at these challenges through a new lens."

The therapy method was developed by Gianneschi while he was a faculty member at UC San Diego, where he is now an adjunct faculty. He continued working on the technology at Northwestern.

This work was made possible by research grants from the National Institutes of Health National Heart, Lung, and Blood Institute.

Source: University of California - San Diego

Published May 2025
