Engineers develop wearable heart attack detection tech

Every second counts when it comes to detecting and treating heart attacks. That's where a new technology from the University of Mississippi comes in to identify heart attacks faster and more accurately than traditional methods.

In a study published in Intelligent Systems, Blockchain and Communication Technologies, electrical and computer engineering assistant professor Kasem Khalil shows that a new technology developed at his lab could improve heart attack detection methods without sacrificing accuracy.

Researchers are developing a lightweight, efficient chip that can be used in wearable devices to detect heart attacks in real time. Detecting a heart attack as it happens can save patients critical time in getting life-saving treatment. [Credit: Graphic by John McCustion/Courtesy of University of Mississippi Marketing and Communications]

"For this issue, a few minutes or even a few extra seconds is going to give this person the care they need before it becomes worse," Khalil said. "Compared to traditional methods, our technology is up to two times faster, while still highly accurate.

"Our target was not only to increase performance for classifying heart attacks. We are also focusing on the design. If we want to make this device a usable machine for any person, that means it has to be something lightweight and economic."

In the United States, someone dies from a heart attack every 40 seconds. Heart disease -- a collection of underlying conditions that can lead to a heart attack -- is the leading cause of death in the United States.

Khalil and his team used artificial intelligence and advanced mathematics to design a chip that can analyze electrocardiograms, known as ECGs -- graphs of the heart's electrical signals -- and detect a heart attack in real time.

The resulting technology is lightweight and energy efficient enough to be embedded in wearable devices while still being 92.4% accurate -- higher than many current methods.

"We wanted to be able to implement this in a way that is real," said Tamador Mohaidat, a doctoral student in Khalil's lab and co-author of the publication. "This is portable hardware that can be in wearable or monitoring devices.

"This method will save lives, because we can monitor the heart in real time."

Mohaidat focused on creating the artificial neural network, while Md. Rahat Kader Khan focused on building the software for the device. Khan, a second-year computer engineering graduate student, said the Khalil lab is unique in that it focuses on all aspects of the technology they hope to create.

"Some labs only focus on the software part, and they don't think about the hardware that's needed," Khan said. "But in our lab, we focus on the whole product. Each of us has a responsibility, but we work together.

"That's how we optimize the whole system, by focusing on the overall architecture."

Current methods of heart attack detection often must happen in a medical facility. A patient experiencing chest pain or who suspects they're having a heart attack must first go through an electrocardiogram or blood tests to diagnose their condition.

All of that takes time that a patient might not have, the researchers said. If a wearable device such as a watch or a phone can cut down on diagnosis time, patients could get faster treatment.

"When a patient is having a heart attack, the sooner you can treat them, the less likely they are to have permanent damage," Khalil said. "There's a huge time-sensitive element to heart attacks."

While Khalil and his team continue developing the technology, he said he sees other healthcare applications for these devices.

"We want to be able to predict or identify many problems using technology like this," he said. "Whether that's heart attacks or seizures or dementia. The detection of a disease or condition depends on the disease itself, but we're working to find faster, more efficient ways of doing that."

Source: University of Mississippi

Published June 2025
