Torpedoes from the air: U.S. Air Force expands QUICKSINK capability to include Stealth Bomber launches

An Airman assigned to the 393rd Bomber Generation Squadron prepares GBU-38 Joint Direct Attack Munitions to be loaded onto a B-2 Spirit stealth bomber at Whiteman Air Force Base, MO. The loading operations were a component of the Air Force Research Laboratory QUICKSINK Joint Capability Technology Demonstration, a new, low-cost, air-delivered capability for defeating maritime threats. [Credit: U.S. Air Force photo by Senior Airman Joshua Hastings/Courtesy of USAF]

In a demonstration of enhanced maritime lethality, the U.S. Air Force recently tested a new, more versatile variant of the QUICKSINK maritime weapon, increasing aircraft lethality by expanding its targeting reach.

QUICKSINK is a low-cost method for neutralizing surface vessels using a modified, air-delivered munition. A 500-lb variant of the anti-ship weapon was delivered recently by a B-2 Spirit Stealth Bomber during a test at the Eglin Air Force Base Gulf Test Range. This innovative capability provides a rapid response to maritime threats across vast ocean expanses, significantly bolstering the U.S. Air Force's counter-maritime deterrence and operations.

"QUICKSINK is the result of a Joint collaboration that rapidly prototyped an affordable concept for holding surface targets at risk," said Col. Matthew Caspers, AFRL Munitions Directorate commander.

Airmen assigned to the 393rd Bomber Generation Squadron load GBU-38 Joint Direct Attack Munitions in a B-2 Spirit stealth bomber at Whiteman Air Force Base, MO. The loading operations were a component of the Air Force Research Laboratory QUICKSINK Joint Capability Technology Demonstration, a new low-cost, air-delivered capability for defeating maritime threats. [Credit: U.S. Air Force photo by Senior Airman Joshua Hastings/Courtesy of USAF]

While torpedoes predominantly sink enemy ships via submarines, new methods explored through QUICKSINK may achieve anti-ship lethality with air-launched weapons, including modified 2,000-lb JDAM precision-guided bombs like the one used in an Air Force QUICKSINK Gulf of Mexico exercise back in 2022.

Four GBU-31/B Joint Direct Attack Munition Bombs are seen loaded on an F15-E Strike Eagle from 85th Test & Evaluation Squadron in this picture released in Aug. 2021. [Credit: U.S. Air Force photo by 1st Lt Lindsey Heflin]

Joint Direct Attack Munition (JDAM) makes "dumb" bombs smart by adding on autonomous navigation capabilities. Using JDAM, QUICKSINK becomes a plug-and-play weapons system that is easily adaptable to different manufacturers' seeker components, so it is a versatile cost-saver.

An Air Force page on the JDAM tech says, "JDAM can be launched from very low to very high altitudes in a dive, toss, or loft, and in straight and level flight with an on-axis or off-axis delivery. JDAM enables multiple weapons to be directed against single or multiple targets on a single pass." As for accuracy, it says, "In its most accurate mode, the JDAM system will provide a weapon circular error probable (CEP) of 5 meters or less during free flight when GPS data is available. If GPS data is denied, the JDAM will achieve a 30-meter CEP or less for free flight times up to 100 seconds with a GPS quality handoff from the aircraft." Range is listed as up to 15 miles.

Kabam. A QUICKSINK missile hits its full-size cargo ship target in the Gulf of Mexico test April 28, 2022. [Credit: U.S. Air Force video screenshots]

"A Navy submarine has the ability to launch and destroy a ship with a single torpedo at any time, but the QUICKSINK JCTD aims to develop a low-cost method of achieving torpedo-like kills from the air at a much higher rate and over a much larger area," said Kirk Herzog, AFRL program manager, about the 2022 test.

VIDEO: Kapow! Watch the AFRL QUICKSINK Joint Capability Technology Demonstration that successfully destroyed a full-scale surface test vessel in the Gulf of Mexico on April 28, 2022. An F-15E Strike Eagle released one modified GBU-31 Joint Direct Attack Munition as part of this test. [Credit: Video by Keith Lewis, Air Force Research Laboratory]

According to Naval News, when the armed fighter detects the target, "It fires an all-weather marine seeker-enabled munition that flies to the target's coordinates. After approaching the target, the seeker tracks its velocity vector and neutralizes it by exploding beneath it, much like a torpedo."

"Heavy-weight torpedoes are effective [at sinking large ships] but are expensive and employed by a small portion of naval assets," said Maj. Andrew Swanson, 85th TES division chief of Advanced Programs. "With QUICKSINK, we have demonstrated a low-cost and more agile solution that has the potential to be employed by the majority of Air Force combat aircraft, providing combatant commanders and warfighters with more options."

A 2,000-lb QUICKSINK munition was also employed successfully during the Rim of the Pacific Exercise (RIMPAC) 2024. The Air Force's new 500-lb variant broadens the B-2's targeting capabilities, providing combatant commanders with an expanded complement of innovative warfighting solutions.
