High-power microwave weapon defeats 49-drone swarm at live-fire demo

A California-based company called Epirus recently disclosed the results of an August 26 demonstration of its Leonidas high-power microwave (HPM) system that delivers weaponized electromagnetic interference to counter swarms of robotic, asymmetric threats (drones).

The live-fire demo tested Leonidas against 61 drones across five operationally relevant flight scenarios. Leonidas' suite of capability differentiators was on full display as the system disabled 61 of 61 drones -- a 100% success rate.

VIDEO: Watch drones fall out of the sky when hit with the Leonidas microwave system at the company's recent demo. [Credit: Epirus]

The event was capped off by performing the defeat of a 49-drone swarm consisting of two threat-representative drone types -- all with one instant and low-collateral pulse of high-energy electromagnetic interference.

Leading up to finale, the prior flight scenarios were: ‍

• Multi-angle counter-swarm engagement. Two groups of three drones were flown in from opposite directions. Leonidas engaged and defeated the first trio of drones to the left then re-directed its HPM beam to engage and defeat the trio of drones to its right.
• Selective targeting. Two drones were flown into the engagement area in close proximity to one another. An audience member chose a drone to be targeted before Leonidas engaged and defeated the correct drone and left the other drone unaffected, demonstrating the system's software-defined, precision-controlled waveforms. Leonidas then engaged and defeated the remaining drone.
• Precision intercept. A single drone flew into the fire zone. Leonidas engaged and defeated the target and dropped it to the ground within a software-defined, pre-identified safe zone. Leonidas is a low-to-no collateral counter-drone solution and uses software to defeat drones exactly when and where operators need to allow for designated safety zones to protect assets and personnel.
• Multi-target engagement. Three drones flew into the fire zone at different ranges. Leonidas engaged and defeated all three drones simultaneously, demonstrating its one-to-many aerial defeat capability.

"This is a watershed moment for Epirus. We believe showcasing our weaponized electromagnetic interference is the most effective way to communicate that Leonidas is the only mission-capable, counter-swarm solution for the one-to-many fight," said Andy Lowery, Epirus CEO. "Those who joined us witnessed this first-hand as 61 drones went up, and 61 went down."

VIDEO: Overview: Asymmetric Drone Warfare -- The Sixth Domain Doctrine by Epirus. [Credit: Epirus]

The invitation-only demonstration took place at Camp Atterbury in Indiana and was attended by representatives from throughout the U.S. Department of Defense, other U.S. government agencies, and nine allied countries. The event was conducted within site range restrictions and optimized for in-person viewing.

What does the Leonidas system look like? Here, in a different demo, the U.S. Army uses the High-Powered Microwave weapon system in a training exercise at Naval Station Leovigildo Gantioqui, Philippines, April 30, 2025. [Credit: U.S. Army photo by Staff Sgt. Brandon Rickert]

The event demonstrated the first generation of Leonidas, which was designed and developed using internal research and development funds in 2022. Epirus unveiled its latest version of Leonidas in July 2025, which is expected to more than double the operational range and lethality over the 2022 system in the same form factor. With the latest system, the company has increased the weapon's effective range to up to 2 km (1.25 miles).

Source: Epirus

Published October 2025
