Rolls-Royce successfully tests first pure methanol high-speed marine engine

The first high-speed, pure methanol engine has celebrated its debut on the test bench at Rolls-Royce, setting a milestone on the road to climate- and environmentally friendly propulsion solutions for ships. [Credit: Image courtesy of Rolls-Royce]

Rolls-Royce has successfully tested the world's first high-speed marine engine powered exclusively by methanol on its test bench in Friedrichshafen, Germany. Together with their partners in the meOHmare research project, Rolls-Royce engineers have reached an important milestone on the road to climate-neutral and environmentally friendly propulsion solutions for shipping. The engine boasts 2,000 kW of power.

"This is a genuine world first," said Dr. Jorg Stratmann, CEO of Rolls-Royce Power Systems AG. "To date, there is no other high-speed engine in this performance class that runs purely on methanol. We are investing specifically in future technologies in order to open up efficient ways for our customers to reduce CO2 emissions and further expand our leading role in sustainable propulsion systems."

Rolls-Royce's goal is to offer customers efficient ways to reduce their CO2 emissions, which is in line with the "lower carbon" strategic pillar of its multi-year transformation program. The project also aligns with the strategic initiative in Power Systems to grow its marine business. The ultimate goal is to develop a comprehensive concept for a CO2-neutral marine engine based on green methanol by the end of 2025.

VIDEO: Rolls-Royce's first methanol engine passes stress test. [Credit: mtusolutions/Rolls-Royce]

Methanol provides new challenges for engineering: unlike diesel, liquid alcohol does not ignite spontaneously and requires a completely new injection technology.

"We have fundamentally redesigned the combustion process, the turbocharging, and the engine control system -- and even adapted our test bench infrastructure," said Dr. Johannes Kech, head of Methanol Engine Development in the Power Systems division at Rolls-Royce. "Initial tests show that the engine is running smoothly -- now it's time for fine-tuning."

The single-fuel methanol engine could be an attractive solution for operators of ferries, yachts, or supply vessels. At the same time, Rolls-Royce is working on a dual-fuel concept that can use both methanol and diesel -- a bridging technology until green methanol is widely available.

Source: Rolls-Royce

Published November 2025
